AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 5 of 150
Document version updates
Revision 2 has the following updates made compared to revision 1, released:
Addition of information on new model of dispenser, AutoLab TF-88
Amended dimensions for all models
Improved photos now included
Reference to water pressure regulator now included with each system
Reference to improved electronic cabinet with mechanical circuit breaker, instead of electrical
Reference to newer design LA50B (600+N2) CPU
Improved wiring diagrams and tables
Configuration for all Mettler, Precisa and Sartorius scales
Improved technical information on servo amplifier, and error codes
Improved troubleshooting guide
Rev 3
Some formatting changes
Rev 4
Additional information on serve motors added
Additional info on fabric weigh scale settings added
Removal of wiring information removed to separate document, TFWIRMAN.doc
Some amendments made to some of the I/O info on pages 48-60
Rev 5
Some amendments made to some of the system sticker information
Additional information on Q type servo amplifier
Update circuit diagram
