1-6-3 Conveyor
Inlet conveyor
The conveyor controls the movement of dye pot tray into dispensing position.
Container sensor
Two of approach sensors detect the type of dye pot tray. There are 4 kinds of type.
Inlet arrival sensor
One of limit sensor detects the arrival of dye pot tray.
Tray inlet push cylinder
This device is used to push the dye pot tray into balance position. After dispensed the
solution, same cylinder will push the tray into second position for dispense auxiliary.
Tray up/down cylinder
This device is used to move up or down the dye pot tray on top of balance. The up or
down position is detected by magnetic sensors.
Middle conveyor
The conveyor controls the movement of dye pot tray into outlet conveyor after
dispensing.
Dye Pot Tray outlet positioning sensor
One limit sensor for detects the arrival of pot’s container.
Container outlet push cylinder
When the outlet arrival sensor detected, the push cylinder will push the dye pot tray into
the outlet conveyor.
Outlet conveyor
This device is used to outlet the dye pot tray.
