AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 48 of 150
2-3-2 AutoLab TF-40 Output Definitions
WIRE NO.
OUTPUT BIT NO.
OF LA50B DIO
DESCRIPTION
CONTROL
DEVICE
EXPLAINATION AutoLab TF-40
000 0 / 0 DIO0 Grab hand Air valve Grabbing Injectors.
001 1 / 0 DIO0
Dispense head
up/down
Air valve
Moving dispense head up/down.
002 2 / 0 DIO0 Anti-drip plate Air valve Moving anti-drip plate in/out.
003 3 / 0 DIO0 Tray up/down Air valve Moving dye pot adapter up/down.
004 4 / 0 DIO0 A zone Inlet Air valve Inlet dye pot to scale or Aux. position.
005 5 / 0 DIO0
A zone
Aux. dispense
head A
Air valve
Moving water dispenses head to front,
middle, back position.
006 6 / 0 DIO0
A zone
Aux. dispense
head B
Air valve
Moving water dispenses head to front,
middle, back position.
007 7 / 0 DIO0 Agitation switch
DS Relay
Board
Switch the agitation on/off.
008 8 / 0 DIO0
Agitation
direction
DS Relay
Board
Control the direction of agitation
(clockwise/anti-clockwise).
009 9 / 0 DIO0
Water dispense
valve A
Water
valve
Open/close water dispensing valve A.
010 10 / 0 DIO0
Water dispense
valve B
Water
valve
Open/close water dispensing valve B.
011 11 / 0 DIO0
Water dispense
valve C
Water
valve
Open/close water dispensing valve C.
013 13 / 0 DIO0
ACK confirm
button
Push
Button
Push the button when to start
dispensing, and it flash in dispensing
014 14 / 0 DIO0 Alarm Alarm
Alarm。
