AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 51 of 150
2-3-4 AutoLab TF-80 Output Definitions
WIRE
NO.
OUTPUT BIT NO.
OF LA50B DIO
DESCRIPTION
CONTROL
DEVICE
EXPLAINATION AutoLab TF-80
000 0 / 0 DIO0 Grab hand Air valve Grabbing Injectors.
001 1 / 0 DIO0
Dispense head
up/down
Air valve
Moving dispense head
up/down.
002 2 / 0 DIO0 Anti-drip plate Air valve Moving anti-drip plate in/out.
003 3 / 0 DIO0 A zone Tray up/down Air valve
Moving dye pot adapter
up/down.
004 4 / 0 DIO0 A zone Inlet Air valve
Inlet dye pot to scale or Aux.
position.
005 5 / 0 DIO0
A zone aux. dispense
head A
Air valve
Moving water dispenses head
to front, middle, back position.
006 6 / 0 DIO0
A zone aux. dispense
head B
Air valve
Moving water dispenses head
to front, middle, back position.
007 7 / 0 DIO0
A zone
Agitation switch
DS Relay
Board
Switch the A zone agitation
on/off.
008 8 / 0 DIO0
A zone
Agitation direction
DS Relay
Board
Control A zone agitation
direction.
(clockwise/anti-clockwise).
009 9 / 0 DIO0
A zone
Water dispense valve A
Water valve
Open/close A zone water
dispensing valve A.
010 10 / 0 DIO0
A zone
Water dispense valve B
Water valve
Open/close A zone water
dispensing valve B.
011 11 / 0 DIO0
A zone
Water dispense valve C
Water valve
Open/close A zone water
dispensing valve C.
012 12 / 0 DIO0
B zone
Agitation switch
DS Relay
Board
Switch the B zone agitation
on/off.
013 13 / 0 DIO0
A zone
ACK confirm button
Push Button
Push the button when start
dispensing, and flash during
dispensing
014 14 / 0 DIO0 Alarm Alarm Alarm。
015 15 / 0 DIO0
B zone
Agitation direction
DS Relay
Board
Control B zone agitation
direction.
(clockwise/anti-clockwise).
019 3 / 1 DIO1 B zone tray up/down Air valve Dye pot up/down weighing.
020 4 / 1 DIO1 B zone Inlet Air valve
Inlet dye pot to scale or Aux.
position.
021 5 / 1 DIO1
B zone aux. dispense
head A
Air valve
Aux. dispenses head moves
front, middle, back for Aux.
dispense.
022 6 / 1 DIO1
B zone aux. dispense
head B
Valve
Aux. dispenses head moves
front, middle, back for Aux.
dispense.
025 9 / 1 DIO1
B zone
Water dispense valve A
Water valve
Control valve of B zone Aux.
A.
026 10 / 1 DIO1
B zone
Water dispense valve B
Water valve
Control valve of B zone Aux.
B.
027 11 / 1 DIO1
B zone
Water dispense valve C
Water valve
Control valve of B zone Aux.
C.
029 13 / 1 DIO1
B zone
ACK confirm button
Push Button
Push the button when to start
dispensing, and it flash in
dispensing
