Datacolor AutoLab TF Series User Manual

AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 50 of 150
WIRE NO.
INPUT BIT
NO. OF
LA50B DIO
DESCRIPTION
TYPE OF
SENSOR
EXPLAINATION AutoLab TF-80
123 7 / 1 DIO1
B zone
Middle sensor of air
cylinder for water
dispensing head.
Magnetic
Water dispenses head above the
dye pots No. 1, 3 and 5.
124 8 / 1 DIO1
B zone
Back sensor of air
cylinder for water
dispensing head.
Magnetic
Water dispenses head is on back
position.
125 9 / 1 DIO1
B zone
Dye pot type identification
sensor1
Magnetic
126 10 / 1 DIO1
B zone
Dye pot type identification
sensor2
Magnetic
1. Both no sensing, dye pot A.
2. Only sensor 1 sensing, dye pot
B.
3. Only sensor 2 sensing, dye pot
C.
4. Both sensing, dye pot D.
129 13 / 1 DIO1
A zone
Confirm button
Push
Button
Push the button when to start
dispensing, and it flash in
dispensing
