AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 56 of 150
2-3-7 AutoLab TF-188/128/168 Input Definition
WIRE
NO.
INPUT BIT NO. OF
LA50B DIO
NAME
CONTROL
DEVICE
EXPLAINATION
AutoLab TF 88/128/168
100 0 OF 0 DIO0 Dye pot tray detector 1 Approach
1. If both senor off, its dye pot tray A
on inlet conveyor (Default
setting).
2. If dye pot tray detector 1 on only,
its dye pot tray B on inlet
conveyor.
3. If dye pot tray detector 2 on only,
its dye pot tray C on inlet
conveyor.
4. If both dye pot tray detector 1 & 2
on, it’s dye pot tray D on inlet
conveyor.
101 1 OF 0 DIO0 Dye pot tray detector 2 Approach See above explanation.
108 8 OF 0 DIO0
Dye pot tray is above
balance
Magnetic
This sensor detected when dye pot
tray is above balance.
109 9 OF 0 DIO0
Dye pot tray is on
balance
Magnetic
This sensor detected when dye pot
tray is on balance and ready to
weighing.
110 10 OF 0 DIO0
Dye pot tray inlet push
front
Magnetic
The cylinder for push dye pot tray
from inlet conveyor is in ready
position. It’s waiting for the dye pot
tray in position.
111 11 OD 0 DIO0
Dye pot tray inlet push
middle
Magnetic
The cylinder for push dye pot tray
from inlet conveyor is in middle
position. The dye pot tray is move to
above balance and weighing.
112 12 OF 0 DIO0
Dye pot tray inlet push
rear
Magnetic
The cylinder for push dye pot tray
from inlet conveyor is in rear position.
The conveyor is move to dispense
auxiliary position.
113 13 OF 0 DIO0
Dye pot tray outlet push
front
Magnetic
The cylinder for push dye pot tray
from outlet conveyor is in ready
position. It’s waiting for the dye pot
tray move to position.
114 14 OF 0 DIO0
Dye pot tray outlet push
rear
Magnetic
The cylinder for push dye pot tray
from inlet conveyor is in rear position.
It’s pushing the dye pot tray and the
outlet conveyor is moving dye pot
tray.
115 15 OF 0 DIO0 Injector exist Infra-red
The sensor is detected the injector
exist in grab hand.
116 0 OF 1 DIO1 Dispense robot in up Magnetic
The dispense robot is in up position.
It’s ready to move robot or down to
grab injector.
117 1 OF 1 DIO1 Dispense robot in down Magnetic
The dispense robot is in down
position. It’s grabbing injector.
118 2 OF 1 DIO1
Anti-dripping device in
front
Magnetic
The Anti-dripping device in front
position when grab injector and
moving robot.
119 3 OF 1 DIO1
Anti-dripping device in
rear
Magnetic
The Anti-dripping device in rear
position and the dispense robot is
able to move down.
120 4 OF 1 DIO1 The hand grab in left
Virtual
(S/W)
There is no physical sensor exist. This
is a software simulation.
121 5 OF 1 DIO1 The hand grab in right
Virtual
(S/W)
There is no physical sensor exist. This
is a software simulation.
122 6 OF 1 DIO1 Dye pot tray inlet position Limit
The container is reach inlet position to
