AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 55 of 150
WIRE
NO.
OUTPUT BIT NO.
OF LA50B DIO
NAME
CONTROL
DEVICE
EXPLAINATION AutoLab
TF-120/160
(clockwise/anti-clockwis
e)
025 9 / 1 DIO1
B zone
Water dispense valve A
Water valve
Control valve of B zone
Aux. A.
026 10 / 1 DIO1
B zone
Water dispense valve B
Water valve
Control valve of B zone
Aux. B.
027 11 / 1 DIO1
B zone
Water dispense valve C
Water valve
Control valve of B zone
Aux. C.
029 13 / 1 DIO1
B zone
ACK confirm button
Push Button
Push the button when
to start dispensing, and
it flash in dispensing
028 12 / 1 DIO1
D zone
Agitation switch
DS Relay
Board
Switch the C zone
agitation on/off.
029 13 / 1 DIO1
B zone
ACK confirm button
Push Button
Push the button when
to start dispensing, and
it flash in dispensing
031 15 / 1 DIO1
D zone
Agitation direction
DS Relay
Board
Control D zone agitation
direction.
(clockwise/anti-clockwis
e)
