AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 57 of 150
WIRE
NO.
INPUT BIT NO. OF
LA50B DIO
NAME
CONTROL
DEVICE
EXPLAINATION
AutoLab TF 88/128/168
push into weighing position.
123 7 OF 1 DIO1
Dye pot tray outlet
position
Limit
The container is reach outlet position
to push into exit position.
124 8 OF 1 DIO1
Auxiliary dispensing
cylinder in front
Magnetic
The auxiliary dispensing head is on
pot 1 & 2 positions.
125 9 OF 1 DIO1
Auxiliary dispensing
cylinder in middle
Magnetic
The auxiliary dispensing head is on
pot 3 & 4 positions.
126 10 OF 1 DIO1
Auxiliary dispensing cylinder
in rear
Virtual
(S/W)
The auxiliary dispensing head is on
pot 5 & 6 positions. There is no
physical sensor exist. This is a
software simulation.
127 11 OF 1 DIO1
Auxiliary calibrating
cylinder in left
Magnetic
The auxiliary dispensing head is on
calibration position.
128 12 OF 1 DIO1
Auxiliary calibrating
cylinder in right
Magnetic
The auxiliary dispensing head is off
calibration position. This is the default
position.
130 14 OF 1 DIO1
Dispensing room secure
sensor
Magnetic
The secure sensors for dispensing
room are all detected. There are
totally 14 sensors in serial connection.
Any one of them is open will interrupt
the movement of robot for safety
reason.
132 0 OF 2 DIO2
The level sensing of
water
Magnetic
The sensor is detected when level in
low position.
133 1 OF 2 DIO2
The level sensing of
auxiliary 1
Magnetic
The sensor is detected when level in
low position.
134 2 OF 2 DIO2
The level sensing of
auxiliary 2
Magnetic
The sensor is detected when level in
low position.
135 3 OF 2 DIO2
The level sensing of
auxiliary 3
Magnetic
The sensor is detected when level in
low position.
136 4 OF 2 DIO2
The level sensing of
auxiliary 4
Magnetic
The sensor is detected when level in
low position.
137 5 OF 2 DIO2
The level sensing of
auxiliary 5
Magnetic
The sensor is detected when level in
low position.
138 6 OF 2 DIO2
The level sensing of
auxiliary 6
Magnetic
The sensor is detected when level in
low position.
139 7 OF 2 DIO2
The level sensing of
auxiliary 7
Magnetic
The sensor is detected when level in
low position.
X SERVO PLC Reset X axis Approach
The sensor is detected when X axis
resetting.
Y SERVO PLC Reset Y axis Approach
The sensor is detected when Y axis
resetting.
Z SERVO PLC Reset Z axis Approach
The sensor is detected when Z axis
resetting.
