AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 59 of 150
WIRE
NO.
OUTPUT BIT NO.
OF LA50B DIO
NAME
CONTROL
DEVICE
EXPLAINATION
AutoLab TF 88/128/168
right auxiliary 6.
031 15 OF 1 DIO1
A
uxiliary 7 dispense
right
Valve
Control the dispensing valve of
auxiliary 7.
033 1 OF 2 DIO2 Auxiliary 1 refill Valve
Control the auxiliary 1 refill when low
level
034 2 OF 2 DIO2 Auxiliary 2 refill Valve
Control the auxiliary 2 refill when low
level
035 3 OF 2 DIO2 Auxiliary 3 refill Valve
Control the auxiliary 3 refill when low
level
036 4 OF 2 DIO2 Auxiliary 4 refill Valve
Control the auxiliary 4 refill when low
level
037 5 OF 2 DIO2 Auxiliary 5 refill Valve
Control the auxiliary 5 refill when low
level
038 6 OF 2 DIO2 Auxiliary 6 refill Valve
Control the auxiliary 6 refill when low
level
039 7 OF 2 DIO2 Auxiliary 7 refill Valve
Control the auxiliary 7 refill when low
level
041 9 OF 2 DIO2 A zone Agitation DS Relay Control switch of A zone Agitator.
042 10 OF 2 DIO2 A zone Agitation DS Relay
Control switch of A zone Agitator.
move forward or backward.
043 11 OF 2 DIO2 B zone Agitation DS Relay Control switch of B zone Agitator.
044 12 OF 2 DIO2 B zone Agitation DS Relay
Control switch of B zone Agitator.
move forward or backward.
045 13 OF 2 DIO2 C zone Agitation DS Relay Control switch of C zone Agitator.
046 14 OF 2 DIO2 C zone Agitation DS Relay
Control switch of C zone
Agitator .move forward or backward.
047 15 OF 2 DIO2 Alarm Alarm Alarm.
