AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 80 of 150
2-3-6 The indication of sticker for TF40/80/120/160
TF-40 sticker and wire no. table
STICKER EXPLAINATION WIRE NO.
HDUD Valves for dispense head up/down 001
GRAB Valve for Grab Hand 000
ANDP Valve for Anti-drip plate 002
XR X approach sensor XR
YR Y approach sensor YR
ZR Z approach sensor ZR
INSR Injector sensor I11
ASUD Valves for Tray A up/down 003
AFED Valves for A Dye pot loading 004
AWHD Valves for A water dispense head 005; 006
AIR INLET Air Inlet
POWER INLET Left side of power entrance
AC220V 1PHASE Up side of power entrance
RS485 RS485 signal wire
DSPSU DC24V power supply
CPU0 First LA50B CPU
SERVO LA50B SERVO
DIO0 First LA50B DIO
XAMP X Servo Amplifier
YAMP Y Servo Amplifier
ZAMP Z Servo Amplifier
DSRLY A DS Relay
FS1 AC220V Fuse
FS2 AC220V Fuse
FS3 DC24V Fuse
FS4 AC24V Fuse
FS5 DC24V Fuse
FS6 DC24V Fuse
R1 Main Power controller
NFB1 Main Power breaker
NFB2 PSU breaker
MC1 Main Power magnetic connector
