AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 83 of 150
TF-40 Air-tube label table
LABEL EXPLAINATION FUNCTION
01 Dispense head up/down valve In
02 Dispense head up/down valve Out
03 Grab hand valve In
04 Grab hand valve Out
05 Anti-drip valve In
06 Anti-drip valve Out
07 Tray up/down valve In
08 Tray up/down valve Out
09 In-let valve In
10 In-let valve Out
11 Aux. front/back valve In
12 Aux. front/back valve Out
TF-80/120/160 Air-tube label table
LABEL EXPLAINATION FUNCTION
01 Dispense head up/down valve In
02 Dispense head up/down valve Out
03 Grab hand valve In
04 Grab hand valve Out
05 Anti-drip valve In
06 Anti-drip valve Out
07 A Tray up/down valve In
08 A Tray up/down valve Out
09 A In-let valve In
10 A In-let valve Out
11 A Aux. front/back valve In
12 A Aux. front/back valve Out
13 B Tray up/down valve In
14 B Tray up/down valve Out
15 B In-let valve In
164 B In-let valve Out
17 B Aux. front/back valve In
18 B Aux. front/back valve Out
