EAN 8

Product Reference Guide

137

EAN 8 — cont.

Expand EAN 8 to EAN 13

Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13.

ENTER/EXIT PROGRAMMING MODE

Expand EAN 8 to EAN 13 = Disable

Expand EAN 8 to EAN 13 = Enable

DEFAULT
