Code 128

Product Reference Guide

187

Code 128 — cont.

Code 128 Function Character Transmission

Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.

ENTER/EXIT PROGRAMMING MODE

Code 128 Function Character Transmission = Don’t Send

Code 128 Function Character Transmission = Send

DEFAULT
