Symbologies

154 QuickScan® QD2100

Add-Ons — cont.

GS1-128 Add-Ons Minimum Reads

This feature specifies the minimum number of times an GS1-128 add-on must be read

before it is marked as valid and then combined with a base label.

ENTER/EXIT PROGRAMMING MODE

GS1-128 Add-Ons Minimum Reads = 1

GS1-128 Add-Ons Minimum Reads = 2

GS1-128 Add-Ons Minimum Reads = 3

GS1-128 Add-Ons Minimum Reads = 4

DEFAULT
