Symbologies

232 QuickScan® QD2100

Codabar — cont.

Codabar Minimum Reads

This feature specifies the minimum number of consecutive times a Codabar label must

be decoded before it is accepted as good read..

ENTER/EXIT PROGRAMMING MODE

Codabar Minimum Reads = 1

Codabar Minimum Reads = 2

Codabar Minimum Reads = 3

Codabar Minimum Reads = 4

DEFAULT
