Symbologies

144 QuickScan® QD2100

Add-Ons

The following features apply to optional add-ons.

Optional Add-ons

The reader can be enabled to optionally read the following add-ons (supplementals):

•P2

•P5

• GS1-128

NOTE

Contact Customer Support for advanced programming of optional

and conditional add-ons.

NOTE

If a UPC/EAN base label and a an add-on are both decoded, the

reader will transmit the base label and add-on. If a UPC/EAN base

label is decoded without an add-on, the base label will be transmitted

without an add-on.

Conditional add-on settings (if enabled) are considered by the reader

before optional add-on settings.

ENTER/EXIT PROGRAMMING MODE

Optional Add-Ons = Disable P2

Optional Add-Ons = Enable P2

Optional Add-Ons = Disable P5

DEFAULT
