Interleaved 2 of 5 (I 2 of 5)

Product Reference Guide

211

Interleaved 2 of 5 (I 2 of 5) — cont.

I 2 of 5 Set Length 2 — cont.

ENTER/EXIT PROGRAMMING MODE

Select I 2 of 5 Length 2 Setting

Make a mistake? Scan the CANCEL barcode to abort and not

save the entry string. You can then start again at the beginning.

CANCEL

DEFAULT

50 = Length 2 is 50 Characters
