Product Reference Guide

369

Digital Interface — cont.

Table 54. Scancode Set When Control Character is 02

X0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF

Cl Cl

BS Tab



S+ Tab Enter

Keypd

Enter Ins

  

F6 F1 F2 F3 F4 F5 ESC F7 F8 F9 F10

2x Space!“#$%&‘()*+,-./

3x 0123456789: ;<=>?

4x @A B C D E F GH I J K LMNO

5x PQRSTUVWXYZ [ \ ] ^ _

6x `abcdefghi jklmno

7x pqr s tuvwxyz{ | }~Del
