Keyboard Interface

70 QuickScan® QD2100

Country Mode — continued

ENTER/EXIT PROGRAMMING MODE

Country Mode = Poland

Supports only the interfaces listed in theCountry Mode feature

description.

Supports only the interfaces listed in theCountry Mode feature

description.

Country Mode = Portugal

Country Mode = Romania

Supports only the interfaces listed in theCountry Mode feature

description.

Supports only the interfaces listed in theCountry Mode feature

description.

Country Mode = Slovakia

Country Mode = Spain

Country Mode = Sweden

Country Mode = Switzerland

Supports only the interfaces listed in theCountry Mode feature

description.
