Datalogic Smart-VS

MODEL SELECTION AND ORDER INFORMATION
PRODUCT REFERENCE GUIDE 24
MODEL SELECTION AND ORDER INFORMATION
INTERNAL LIGHTING SYSTEM
The Smart-VS Plus illuminator is composed of 4 white LEDs with polarized filter.
Figure 9 - Smart-VS Plus illuminator
ACCESSORIES
The following accessories can be used with Smart-VS Plus.
Model SMART-VS-PL-5-150-WH-O
Description SVS PLUS DIG OUT
Optics 7 mm
Illuminator White polarized
I/O 3 OUT + 2 IN + ETH
Order number 959970005
Accessory Order No.
Cables
CAB-GD03 M12-17P 3M power and I/O cable, isolated wires 95A900052
CAB-GD05 M12-17P 5M power and I/O cable, isolated wires 95A900053
M12-IP67 GIGA Ethernet Cable X-Coded (1M) 93A050122
M12-IP67 GIGA Ethernet Cable X-Coded (3M) 93A050123
M12-IP67 GIGA Ethernet Cable X-Coded (5M) 93A050124
Adapter Cable GIGA Ethernet X-Coded M12 to RJ45 93A050128
Adapter Cable GIGA Ethernet X-Coded to Ethernet D-Coded 93A050129
Bracket
BK-22-000 Fixing Bracket M220 Body 93ACC0230
