Datalogic Smart-VS

PRODUCT REFERENCE GUIDE 46
ENVIRONMENTAL FEATURES
Operating Temperature
a
a. high ambient temperature applications should use metal mounting bracket for heat dissipa-
tion.
0 to 50 C (32 to 122 °F)
Storage Temperature -20 to 70 °C (-4 to 158 °F)
Max. Humidity 90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 500 Hz; 2 hours on each axis
Shock Resistance
EN 60068-2-27
30g; 11 ms;
3 shocks on each axis
Protection Class
b
EN 60529
b. when correctly connected (fully tightened) to IP67 cables with seals.
IP65 and IP67
PHYSICAL FEATURES
Dimensions
Smart-VS with connector at 0°
Smart-VS with connector at 90°
H x W x L
78 x 47 x 38 mm (3.1 x 1.9 x 1.5 in)
58 x 47 x 58 mm (2.3 x 1.9 x 2.3 in)
Weight 173 g (6.1 oz)
Material Aluminum with PMMA protective window cover
