REFERENCES

135

Set Length 2

This feature specifies one of the barcode lengths for Length Control. Length 2 is the

maximum label length if in Variable Length Mode, or the second fixed length if in Fixed

Length Mode.

The length that can be set varies depending on the symbology. For Fixed Length Mode, a

setting of 0 specifies to ignore Length 2 (use only Length 1). Reference the page for your

selected symbology to see specific variables.

NOTE

Code 39, Code 128, I 2/5, S 2/5, Code 11, Code 93, MSI

The specified length includes the check character (if any), data and ASCII

shift characters. It does not include the start/stop characters.

NOTE

Codabar

The specified length includes the check character (if any), data and the

start/stop characters.

Follow these instructions to set this feature:

1. Determine the desired character length (varies depending on symbology).

2. Use the Chart in Appendix C to find the hex equivalent(s)

for the desired numeric value.

3. Go to the Set Length page for your selected symbology and scan the ENTER/EXIT

PROGRAMMING MODE barcode to enter Programming Mode.

4. Scan the barcode to SELECT LENGTH 2 SETTING for your selected symbology.

5. Scan the two hex equivalent characters

from the keypad in Appendix B that represent the

numeric value determined in step 1 above.

NOTE

If you make a mistake before the last character, scan the CANCEL barcode

to abort and not save the entry string. You can then start again at the

beginning.

6. Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.

This completes the procedure.

Datalogic TC1200 User Manual
