TC1200 REFERENCE MANUAL
136
6
6 TECHNICAL FEATURES
Electrical Features RS232 USB
Power supply
5 Vdc 5%
Consumption 350 mA; 1.75 W
Interfaces RS232, USB
Inputs
Input 1 (External Trigger),
Voltage
Current Consumption
Minimum Pulse Duration
Optocoupled, polarity insensitive
5 to 30 Vdc
9 mA max.
5 ms
Outputs
Output 1, Output 2
V
CE
Collector Current
V
CE Saturation
Power Dissipation
Optocoupled
30 Vdc max.
40 mA continuous max.; 130 mA pulsed max.
1V max. at 10 mA
80 mW max. at 45 °C (ambient temperature)
Reading Features
Max Scans/sec 320
Max resolution 0.076 mm (3mils)
Readable codes:
EAN/UPC, Code 39, Code 32, Code 128, GS1-128,
ISBT 128, Interleaved and Standard 2 of 5, Codabar,
ABC Codabar, GS1 Databar (Omnidirectional, Limited,
Expanded), Code 93, Code 11, MSI
Physical Features Scanner Scan Engine
RS232 USB RS232 USB
Width 57 mm (2.24 inches) 50 mm (1.96 inches)
Length 50 mm (1.96 inches) 43 mm (1.69 inches)
Height 31 mm (1.22 inches) 21 mm (0.82 inches)
Weight - max. 120 g.
(4.2 oz.)
105 g.
(3.7 oz.)
30 g.
(1 oz.)
Environmental Features
Operating Temperature 0° to +50 °C (+32° to +122 °F)
Storage Temperature -20° to +70 °C (-4° to +158 °F)
Humidity max. 90% non condensing
Protection Class
EN 60529
IP64 -
