TC1200 REFERENCE MANUAL
8
2
2.2 TC1200 CCD SCAN ENGINE
2.2.1 Mechanical Installation
The diagram below gives the overall dimensions of the TC1200 Scan Engine and may be
used for its installation.
50
[1.97]
43
[1.69]
20.8
[0.82]
12.7
[0.50]
5
[0.20]
44
[1.73]
3
[0.12]
3
[0.12]
31
[1.22]
1.5
[0.06]
4.8
[0.19]
9.3
[0.36]
16.8
[0.66]
34
[1.34]
39
[1.54]
Ø2.3
[Ø0.09] N°3
3.1
[0.12]
31.1
[1.22]
Figure 10 - Overall Dimensions
Optical Axis
