Enter/Exit
Configuration
CODE SELECTION
ËÄ$PmIÎ
106
Code 93 Check Options
C
HECK
C
ALCULATION
Disable
ËÄ$CC9CC00m.Î
Enable Check C
Enable Check K
ËÄ$CC9CC01m7Î
ËÄ$CC9CC02m@Î
Enable Check C and K
ËÄ$CC9CC03mIÎ
C
HECK
T
X
Disable
ËÄ$CC9CT00m>Î
Enable
ËÄ$CC9CT01mGÎ
117
119
Table of Contents
Default Chapter
3
Default Chapter
3
Table of Contents
3
References
9
Conventions
9
Reference Documentation
9
Services and Support
9
Patents
9
Safety and Compliance Notices
10
FCC Compliance
10
Power Supply
10
CE Compliance
10
Handling
11
1 Introduction
13
Configuration Methods
13
Configuration Using Datalogic Aladdin
13
Configuration Using Serial Programming Strings
13
Configuration Using Programming Barcode Labels
13
BUTTON and LED Indicators
14
Available Models
14
2 Installation
15
TC1200 CCD Scanner
15
Mechanical Installation
15
Electrical Connections
16
TC1200 CCD Scan Engine
20
Mechanical Installation
20
Electrical Connections
21
Usb Interface
22
Positioning
25
3 Software Configuration Strings
26
TC1200 Configuration
26
Command Syntax
27
4 Barcode Configuration
43
Initial Setup
43
Restore Default
43
Interface Selection
43
Changing Default Settings
45
Global Interface Features
46
Rs232
47
Data Bits
47
Baud Rate
48
Parity
48
Stop Bits
49
Rs232/Usb-Com
50
Intercharacter Delay
51
Disable Character
51
Enable Character
51
ACK/NAK Options
51
ACK Character
51
NAK Character
52
ACK/NAK Timeout
52
ACK/NAK Retry Count
52
ACK/NAK Error Handling
52
Usb-Kbd
53
Keyboard Country
54
Keyboard Country (Continued)
55
Keyboard Intercode Delay
55
Send Control Characters
56
USB Keyboard Speed
56
USB Keyboard Speed (Continued)
57
Reading Parameters
58
Illumination Mode
58
Operating Mode
58
Automatic Threshold
59
Phase off Event
60
Timeout
60
Serial Start
60
Serial Stop
60
LED Indication
60
Label Programming Mode
61
Data Format
62
Data Transmission
62
Code Verifier Mode
63
Match String
63
Wrong Code String
63
Case Conversion
64
Global Prefix
64
Global Suffix
64
No Read String
64
Transmit AIM Ids
65
Transmit Custom Label Ids
65
Custom Label Identifiers
65
Custom Label Identifiers (Continued)
66
Custom Label Identifiers (Continued)
67
Custom Code Identifiers (Continued)
68
Digital Outputs
69
Output 1 Activation Event
70
Output 1 Deactivation Event
70
Output 1 Deactivation Timeout
70
Output 2 Activation Event
71
Output 2 Deactivation Event
71
Output 2 Deactivation Timeout
71
Power Save
72
Sleep Mode Timeout
73
Code Selection
74
Upc-A
75
Check Character Tx
75
Expand to EAN-13
75
Number System Tx
75
UPC-A Minimum Reads
76
Coupon Control
76
Upc-E
77
Check Character Tx
77
Expand to UPC-A
77
Expand to EAN-13
77
Number System Tx
78
UPC-E Minimum Reads
78
Check Character Tx
79
ISBN Conversion
79
ISSN Conversion
79
Flag 1 Character
80
Minimum Reads
80
Coupon Control
80
Check Character Tx
81
Expand to EAN-13
81
Minimum Reads
81
Enable Optional P2 Add-On
82
Enable Optional P5 Add-On
82
P2 Minimum Reads
82
P5 Minimum Reads
83
Optional Add-On Timer
83
GTIN Format
84
Decoding Level
84
Character Correlation
84
In-Store Minimum Reads
85
Code 39
85
Code 39 Full ASCII
85
Code Length Control
85
Set Length
86
Code 39 Check Tx
86
Code 39 Start/Stop Tx
86
Code 32 (Italian Pharmaceutical)
87
Code 32 Check Tx
87
Code 32 Start/Stop Tx
87
Check Calculation
88
Minimum Reads
88
Decoding Level
89
Character Correlation
89
Interdigit Ratio
89
Quiet Zones
90
Stitching
90
Code 128
91
GS1-128 Enable
91
Code Length Control
91
Set Length
91
Expand to Code 39
92
Check Tx
92
Function Character Tx
92
Sub-Code Change Tx
92
Minimum Reads
93
Decoding Level
93
Character Correlation
94
Quiet Zones
94
Stitching
94
ISBT 128 Concatenation
95
Concatenation Mode
95
Dynamic Concatenation Timeout
95
Interleaved 2 of 5
96
Code Length Control
96
Set Length
96
Check Calculation
97
Check Tx
97
Minimum Reads
98
Decoding Level
98
Character Correlation
99
Stitching
99
Zero Pattern
99
Standard 2 of 5
100
Code Length Control
100
Set Length 1
100
Check Calculation
100
Check Tx
101
Minimum Reads
101
Decoding Level
102
Character Correlation
102
Stitching
102
Codabar
103
Code Length Control
103
Set Length
103
Codabar ABC
104
Concatenation Mode
104
Dynamic Concatenation Timeout
104
Check Calculation
105
Check Tx
105
Start/Stop Set
105
Start/Stop Tx
106
Start/Stop Match
106
Minimum Reads
106
Decoding Level
107
Character Correlation
107
Interdigit Ratio
107
Quiet Zones
108
Stitching
108
Code 11
109
Code Length Control
109
Set Length
109
Check Calculation
110
Check Tx
110
Minimum Reads
111
Decoding Level
111
Character Correlation
112
Interdigit Ratio
112
Stitching
112
GS1 Databar Omnidirectional
113
GS1 Databar Omnidirectional GS1-128 Emulation
113
Minimum Reads
113
GS1 Databar Expanded
114
GS1 Databar Expanded GS1-128 Emulation
114
Code Length Control
114
Set Length 1
114
Minimum Reads
115
Coupon Control
115
GS1 Databar Limited
116
GS1 Databar Limited GS1-128 Emulation
116
Minimum Reads
116
Code 93
117
Code Length Control
117
Set Length 1
117
Check Calculation
118
Check Tx
118
Minimum Reads
119
Decoding Level
119
Character Correlation
120
Quiet Zones
120
Stitching
120
Msi
121
Code Length Control
121
Set Length 1
121
Check Calculation
122
Check Tx
122
Minimum Reads
123
Decoding Level
123
Stitching
124
5 Parameter References
125
RS232 Parameters
125
RS232 Only
125
RS232/USB COM Parameters
126
Ack Nak Timeout Value
129
Reading Parameters
130
Illumination Mode
130
Operating Mode
131
Good Read LED
134
Data Formatting
135
Global Prefix/Suffix
136
Code Identifiers
138
Global Aim ID
140
Code Verifier
141
Digital Outputs
142
Activation Event
142
Deactivation Event
142
Power Save
143
Code Selection
143
Concatenation
145
Set Length 1
146
Set Length 2
147
6 Technical Features
148
Reading Diagrams
149
Adefault Parameters Table
150
Keypad
154
Reserved Characters
158
Declaration of Conformity
159
