INTRODUCTION
1
1
1 INTRODUCTION
The TC1200 compact CCD reader is the perfect solution for many OEM applications. It
contains a built-in decoder
and multi-standard interface. Due to its well-balanced mix of
technical characteristics it is perfect for integration into custom equipment, setting a new
standard in this product class.
This Reference Manual provides connection diagrams, default parameter listing, complete
application parameter settings, specific technical features and reading diagrams.
1.1 CONFIGURATION METHODS
1.1.1 Configuration Using Datalogic Aladdin™
(for RS232/USB-COM Interfaces)
The easiest way to configure TC1200 is by using the Datalogic Aladdin™ utility program
downloadable from: www.automation.datalogic.com
.
Aladdin allows you to program the TC1200 reader by selecting configuration commands
through a user-friendly graphical interface running on a PC. These commands are sent to the
reader over the selected communication interface, or they can be printed as barcodes to be
scanned.
Aladdin also provides Help On-Line files explaining how to use the program as well as
descriptions of the configuration parameters.
Aladdin also provides the ability to perform a software upgrade for the connected device (see
the Datalogic Aladdin™ Help On-Line for more details).
1.1.2 Configuration Using Serial Programming Strings
(for RS232/USB-COM Interfaces)
This manual contains the complete
set of command strings for TC1200 configuration. These
strings can be sent via the RS232/USB-COM interface using a terminal emulator such as
HyperTerminal.
Refer to Chapter 3 of this manual for configuration procedures using Serial Strings sent by
the Host.
1.1.3 Configuration Using Programming Barcode Labels
(for all Interfaces)
Refer to Chapter 4 of this manual for configuration procedures using Programming Bacode
Labels.
