ES601Plus OPERATING MANUAL
AUX1 Terminal (MAP):
- CAT I
- Max Voltage: 264 VAC out
- Max Current: 2mA AC out
AUX2 Terminal:
- CAT I
- Max Voltage: PE potential
- Max Current: 6.5mA AC, 20mA DC
To DUT Case Terminal:
- CAT I
- Max Voltage: PE Potential
- Max Current: 40 A AC
Applied Parts Terminals:
- CAT I
- Max Voltage: 264 VAC (MAP Test ), 500 VDC (Insulation Test)
- Max Current: 14mA AC @264 VAC, 50mA DC @ 500 VDC
Connect measurement terminals ONLY as instructed in this manual, see
Chapter 4, Connecting to ES601
1.5 ECG Simulator
Performance Waveforms
- DC Pulse: 4 seconds
- Square Wave: 2 Hz
- Triangle Wave: 2 Hz
- Havertriangle Pulse: 10, 25, 40, 100 and 200 msec, @ 60 BPM
- Sine Wave: 0.5, 10, 20, 40, 50, 60, 70 and 100 Hz
- Normal Sinus Rhythm: 30, 60, 90, 120, 150, 180, 240 and 300 BPM
Specifications/Chapter 1 # Page 3
