ES601Plus OPERATING MANUAL
6.2.5.10 Instruction Summary
Op Code Instruction Type Buttons shown on LCD
A Run AutoSequence ESCAPE; BACK; SKIP; CONTINUE
C Tester Remote Control If no tester response: ESCAPE; BACK; NEXT
D Timed Delay, in seconds ESCAPE; BACK; SKIP
E Data Entry with Pass/Fail ESCAPE; PASS; FAIL; FAULT CORRECTED;
BACK; SKIP; ENTER TEST DATA
I Input Requested QWERTY touch keypad
K OK Prompt ESCAPE; BACK; OK
M Tester Measurement ESCAPE; PASS; FAIL; BACK; SKIP
P Pass/Fail ESCAPE; PASS; FAIL; BACK; SKIP;
FAULT CORRECTED
R Tester Remote Control with
User Data Entry
ESCAPE; PASS; FAIL; FAULT CORRECTED;
BACK; SKIP; ENTER TEST DATA
Automated Testing/Chapter 6 # Page 129
