Datum Systems M7 Series - Page 118

Maintenance M7/M7L/M7LT Modular Satellite Modem
3-62 M7/M7L/M7LT - Rev. 0.05
E7 Interface Parameters
Representation
Type
Entry
Description
Status Port 3
UNCONNECTED
Read Only
N/A
Port 3 Status
Status Port 4
Disabled
Read Only
N/A
Port 4 Status
Status Port 5
Not Installed
Read Only
N/A
SFP Port 5 Status
Status Send Buffer
0 ms Data Backlog
Read Only
N/A
Input Ethernet Buffer Status
Status Send Data
Active, Ok
Read Only
N/A
Send Data Activity Status
Status Rcv Data
Active, Ok
Read Only
N/A
Rcv Data Activity Status
Status Ref Relay
Locked OK
Read Only
N/A
Future Option
Status Test
Normal
Read Only
N/A
Interface Test status
Status Hardware Type
E7 Express Interface
Read Only
N/A
Indicates the type of the active
interface
Status Hardware Ver
M709017A-1r9.91
Read Only
N/A
Indicates the part number of the
active interface
Status Hardware S/N
100360
Read Only
N/A
Indicates the serial number of the
active interface
I/O Port 1 Mode
Data I/O
Selection
0 = Disable,
1 = Data I/O
2 = Dmd Output I/O
3 = Dmd Input I/O
Sets the mode of the Ethernet
Port
I/O Port 1 Connection
Auto
Selection
0 = Auto,
1 = 1000BASE-T
2 = 100BASE-T Full
Duplex
3 = 100BASE-T Half
Duplex
4 = 10BASE-T Full Duplex
5 = 10BASE-T Half
Duplex
Sets the connection type of the
Ethernet Port
I/O Port 1 VLAN ID
1
Numeric
Valid ID: 1 to 4094,
0 = Disabled,
4095 reserved
VLAN ID for Port 1
I/O Port 2 Mode
Data I/O
Selection
0 = Disable,
1 = Data I/O
2 = Dmd Output I/O
3 = Dmd Input I/O
Sets the mode of the Ethernet
Port
