M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-63
E7 Interface Parameters
Representation
Type
Entry
Description
I/O Port 2 Connection
Auto
Selection
0 = Auto,
1 = 1000BASE-T
2 = 100BASE-T Full
Duplex
3 = 100BASE-T Half
Duplex
4 = 10BASE-T Full Duplex
5 = 10BASE-T Half
Duplex
Sets the connection type of the
Ethernet Port
I/O Port 2 VLAN ID
4094
Numeric
Valid ID: 1 to 4094,
0 = Disabled,
4095 reserved
VLAN ID for Port 2
I/O Port 3 Mode
Data I/O
Selection
0 = Disable,
1 = Data I/O
2 = Dmd Output I/O
3 = Dmd Input I/O
Sets the mode of the Ethernet
Port
I/O Port 3 Connection
Auto
Selection
0 = Auto,
1 = 1000BASE-T
2 = 100BASE-T Full
Duplex
3 = 100BASE-T Half
Duplex
4 = 10BASE-T Full Duplex
5 = 10BASE-T Half
Duplex
Sets the connection type of the
Ethernet Port
I/O Port 3 VLAN ID
Disabled
Numeric
Valid ID: 1 to 4094,
0 = Disabled,
4095 reserved
VLAN ID for Port 3
I/O Port 4 Mode
Data I/O
Selection
0 = Disable,
1 = Data I/O
2 = Dmd Output I/O
3 = Dmd Input I/O
Sets the mode of the Ethernet
Port
I/O Port 4 Connection
Auto
Selection
0 = Auto,
1 = 1000BASE-T
2 = 100BASE-T Full
Duplex
3 = 100BASE-T Half
Duplex
4 = 10BASE-T Full Duplex
5 = 10BASE-T Half
Duplex
Sets the connection type of the
Ethernet Port
I/O Port 4 VLAN ID
Disabled
Numeric
Valid ID: 1 to 4094,
0 = Disabled,
4095 reserved
VLAN ID for Port 4
I/O Port 5 Mode
Data I/O
Selection
0 = Disable,
1 = Data I/O
2 = Dmd Output I/O
3 = Dmd Input I/O
Sets the mode of the Ethernet
Port
