E7 Interface Parameters
Representation
Type
Entry
Description
I/O Port 5 Connection
Auto
Read Only
0 = Auto
Sets the connection type of the
Ethernet Port
I/O Port 5 VLAN ID
Disabled
Numeric
Valid ID: 1 to 4094,
0 = Disabled,
4095 reserved
VLAN ID for Port 5
Send WAN Mode
Bridge PTP
Selection
0 = Bridge PTP
1 = Hub Bridge PTMP
2 = Remote Bridge PTMP
3 = Mesh Bridge
Sets the WAN network type
Send WAN Protocol
M7 HDLC
Selection
0 = M7 HDLC
1 = M500 HDLC
Sets the protocol of the HDLC for
legacy support
Rcv WAN Mode
Bridge PTP
Selection
0 = Bridge PTP
1 = Hub Bridge PTMP
2 = Remote Bridge PTMP
3 = Mesh Bridge
Sets the WAN network type
Rcv WAN Protocol
M7 HDLC
Selection
0 = M7 HDLC
1 = M500 HDLC
Sets the protocol of the HDLC for
legacy support
QOS Mode
WRED
Selection
0 = WRED
1 = Strict Priority
Sets the flow control mode
QOS WAN Drop None
< 50 ms
Numeric
Set value in mSec
Sets the time before an the WAN
buffer will initiate flow control
QOS WAN Drop All
> 2938 ms
Numeric
Set value in mSec
Sets the time before a the WAN
buffer will drop all packets that
overfills the buffer.
Stats Send Data PPS
38.871 kpps
Read Only
Indicates the Send rate of the
Ethernet Data traffic
Stats Send Data Packets
7.812E7
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the number of Ethernet
packets sent
Stats Send Data Bytes
9.374E9
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the number of Ethernet
Bytes sent
Stats Send Data Usage
80.42%
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the percentage of the
WAN link that is used by the
Ethernet port
Stats Send MCC Packets
3.413E3
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the number of MCC
packets sent
Stats Send MCC Bytes
9.374E4
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the number of MCC
Bytes sent
Stats Send MCC Usage
18.56%
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the percentage of the
WAN link that is used by the
MCC port
Stats Send Idle Packets
3.413E3
Read Only
Press “Edit” then "Enter"
to reset the counter
Indicates the number of Idle
packets sent
