M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-37
Unit Parameters
Representation
Type
Entry
Description
IP Control M&C Remote Path
192.168.002.201
Numeric
Enter IPv4 address
This address is used with the
Demod IF AUPC Remote
Path setting of “Out IP Control
Port” to set the proper
destination address for the
MCC data that is received by
the demodulator.
IP Control M&C Ext Device
_ _ _ . _ _ _ . _ _ _ . _ _ _
Numeric
Enter IPv4 address (can
remain blank)
This address is set to identify
an external device that is to
receive UDP packets.
IP Control M&C Activity
None
Selection
0 = None,
1 = Beep,
2 = Blink Online Lamp,
3 = Beep & Blink Online
Audible “beep” and/or “Online”
LED Blink on IP Control M&C
port activity.
Remote IP MAC Address
00:19:78:00:0a:9e
Read Only
Not changeable
Displays the MAC address of
the modem controller
Control RS-232 Mode
Full Access
Selection
0 = Disable,
1 = Read Only,
2 = Full Access.
Remote control access mode
allowed
Control RS-232 Protocol
M7 Binary Packet
Selection
0 = VT100,
1 = Quiet VT100,
2 = M7 Binary Packet,
Remote control mode type
Control RS-232 Address
1
Numeric
0 to 254
0 = address disabled
255 = global
Address used to access this
unit via remote control and
USB packets.
Control RS-232 Rate
9600 bps
Selection
0 to 8 selects 300 to 57,600
bits per second.
Remote port bit rate
Control RS-232 Format
N,8,1
Selection
0 = N,8,1
1 = E,8,1
2 = O,8,1
3 = M,8,1
4 = S,8,1
Remote control data/stop bits
and parity. Always 8 data bits
and 1 stop bit. N= No Parity,
E = Even, M = Mark,
S = Space.
Control RS-232 Activity
Blink Online Lamp
Selection
0 = None,
1 = Beep,
2 = Blink Online Lamp,
3 = Beep & Blink Online
Audible “beep” and/or “Online”
LED Blink on Remote port
activity.
Control RS-485 Mode
Full Access
Selection
0 = Disable,
1 = Read Only,
2 = Full Access.
Remote control access mode
allowed
Control RS-485 Protocol
M7 Binary Packet
Selection
0 = VT100,
1 = Quiet VT100,
2 = Binary Packet,
Remote control mode type
Control RS-485 Address
101
Numeric
0 to 255
0 = address disabled
255 = global
Address used to access this
unit via remote control and
USB packets.
Control RS-485 Rate
9600 bps
Selection
0 to 8 selects 300 to 57,600
bits per second.
Remote port bit rate
