Datum Systems M7 Series - Page 92

Maintenance M7/M7L/M7LT Modular Satellite Modem
3-36 M7/M7L/M7LT - Rev. 0.05
Unit Parameters
Representation
Type
Entry
Description
SNMP Trap Community
datum
Alpha –
Numeric
Up to 24 characters and can
contain any combination of
alphanumeric characters,
hyphens (-), and underscore
characters (_).
Set the Trap community name
for authentication for SNMP
traffic.
SNMP Trap Address
192.168.2.101
Numeric
Enter IPv4 address
Set the IP Address for the
SNMP Trap
SNMP Trap Port Number
162
Numeric
1 to 65535
162 = IANA
Set the Internet socket port
number for the SNMP trap
SNMP Trap Keep-Alive
Disable
Numeric
0 = Disable
1 to 99999 Sec
Disable or set the time for the
Trap message to the SNMP
host to ensure that the link
between them is operational.
SNMP Server Activity
None
Selection
0 = None,
1 = Beep,
2 = Blink Online Lamp,
3 = Beep & Blink Online
Audible “beep” and/or “Online”
LED Blink on SNMP port
activity.
SNMP MIB Version
1.0.3h
Read Only
N/A
Read only indication of the
MIB version
IP Control DHCP
Enable
Selection
0 = Disable,
1 = Enable
IP Address of the IP Control
Port is selected via DHCP or
manually
IP Control Address
192.168.002.122
Numeric
Enter IPv4 address
If DHCP is Disabled, manually
enter the IP Control Port IPv4
Address
IP Control Network Mask
255.255.255.000
Numeric
Enter IPv4 Network Subnet
Mask
If DHCP is Disabled, manually
enter the IP Control Port IPv4
Subnet Mask
IP Control Gateway
_ _ _ . _ _ _ . _ _ _ . _ _ _
Numeric
Enter IPv4 Default Gateway
Address (can remain blank)
If DHCP is Disabled, manually
enter the IP Control Port IPv4
Default Gateway
IP Control DNS 1
208.067.222.222
Numeric
Enter IPv4 Domain Name
Server Address (can remain
blank)
If DHCP is Disabled, manually
enter the IP Control Port IPv4
DNS1 Server Address
IP Control DNS 2
208.067.220.220
Numeric
Enter IPv4 Domain Name
Server Address (can remain
blank)
If DHCP is Disabled, manually
enter the IP Control Port IPv4
DNS 2 Server Address
IP Control M&C Server Mode
Full Access
Selection
0 = Disable,
1 = Read Only,
2 = Full Access.
Control access and mode of
the UDP packet protocol.
IP Control M&C Port Number
9101
Numeric
200 to 65535
UDP Port number that is used
for modem control
