M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-39
Unit Parameters
Representation
Type
Entry
Description
Event Power Supply Alarm
Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set and
alert for the Power Supply
Mask alarm
Event System
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
activity of “System” events.
System events include:
Recalled or Stored
configuration, Firmware flash
updates, Buffer slips, DHCP
address acquired, etc.
Event HTTP Access
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log activity
of the HTTP port
Event SNMP Access
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log activity
status of the SNMP port
Event Cold/Warm Start
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log a Cold
or Warm Start (power cycle or
system reset).
Event Minor Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
activity of any Minor alarms
Event Major Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
activity of any Major alarms
Event Test Active
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
status of the Test Active alarm
Event Hardware Alarm
Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set an alert
for the status of the Hardware
alarm
Alarm Event Pending Mask
to Alarm A & B
Selection
0=None, 1=to Alarm A, 2=to
Alarm B, 3=to Alarm A & B,
4 = Flash Online Only
5 = Flash Minor Alm Only
Selects destination and action
taken when an event of any
kind has been logged.
Alarm Reference Mask
to Alarm A & B
Selection
0=None, 1=to Alarm A, 2=to
Alarm B, 3=to Alarm A & B,
4 = Mute CXR, 5 = Mute CXR
& Alarm A, 6 = Mute CXR &
Alarm B, 7 = Mute CXR &
Alarm A & B
Selects destination and action
taken for reference oscillator
alarm types.
Alarm IP Control Port Mask
to Alarm A & B
Selection
0=None, 1=to Alarm A, 2=to
Alarm B, 3=to Alarm A & B,
4 = Mute CXR, 5 = Mute CXR
& Alarm A, 6 = Mute CXR &
Alarm B, 7 = Mute CXR &
Alarm A & B
Selects destination and action
taken for the IP Control Port
status
