Detailed Parameters
Section 4
DriveRack
™
23
DriveRack™ User Manual
4.5.2 LINKED STEREO FILTER
Filter Type 1 - Wire, Lowpass, Highpass and Bandpass
Selects the desired filter type.
Lowpass 1 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
Highpass 1 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Low Slope 1 - 6-24dB/Octave (filter type dependent)
Sets the Lowpass slope of the crossover filter.
High Slope 1 - 6-24dB/Octave
Sets the High pass slope of the crossover filter.
Type - Butterworth (BW), Bessel (BS) and Linkwitz-Riley(L-R)
Selects the desired crossover filter type.
4.5.3 2-BAND CROSSOVERS - 1X2, 2X4
Low Frequency rolloff 1 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
High Frequency rolloff 1 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Type 1 - Butterworth (BW), Bessel (BS) and Linkwitz-Riley(L-R)
Selects the desired crossover filter type.
Low Slope 1 - 6-24dB/Octave (BW, Bessel) 12-48dB/Octave (L-R)
Sets the Lowpass slope of the crossover filter.
High Slope 1 - 6-24dB/Octave (BW, Bessel) 12-48dB/Octave (L-R)
Sets the Highpass slope of the crossover filter.
Low Frequency rolloff 2 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
High Frequency rolloff 2 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Type 2 - Butterworth (BW), Bessel (BS) and Linkwitz-Riley(L-R)
Selects the desired crossover filter type.
Low Slope 2 - 6-24dB/Octave (BW, Bessel) 12-48dB/Octave (L-R)
Sets the Lowpass slope of the crossover filter.
High Slope 2 - 6-24dB/Octave (BW, Bessel) 12-48dB/Octave (L-R)
Sets the Highpass slope of the crossover filter.
