Detailed Parameters
®
24
Section 4
DriveRack
™
DriveRack™ User Manual
Section 4
4.5.4 3-BAND CROSSOVERS - 1X3
Low Frequency rolloff 1 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
High Frequency rolloff 1 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Type 1 - Butterworth (BW), Bessel and Linkwitz-Riley(L-R)
Selects the desired cross-over filter type.
Low Slope 1 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the slope of the crossover filter.
High Slope 1 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the Highpass slope of the crossover filter.
Low Frequency rolloff 2 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
High Frequency rolloff 2 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Type 2 - Butterworth (BW), Bessel (BS) and Linkwitz-Riley(L-R)
Selects the desired crossover filter type.
Low Slope 2 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the Lowpass slope of the crossover filter.
High Slope 2 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the Highpass slope of the crossover filter.
Low Frequency rolloff 3 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
High Frequency rolloff 3 - 20Hz to 20kHz
Selects the desired Highpass crossover frequency.
Type 3 - Butterworth (BW), Bessel (BS) and Linkwitz-Riley(L-R)
Selects the desired crossover filter type.
Low Slope 3 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the Lowpass slope of the crossover filter.
High Slope 3 - 6-24dB/Octave (BW, Bessel) 12-24dB/Octave (L-R)
Sets the Highpass slope of the crossover filter.
4.5.5 4-BAND CROSSOVERS - 1X4
Low Frequency rolloff 1 - 20Hz to 20kHz
Selects the desired Lowpass crossover frequency.
