All 4 channels are linkable
Dynamics
Type: Compressor/Limiter with PeakStopPlus™
Attack/Release: Program Dependent
Linking: All 4 parameters are linkable
Post Delay (Driver Alignment)
Length: 365.32 ms per output channel
All 4 parameters are linkable
Phase Compensation
Number: One per output channel
Amount: 0-360 degrees phase shift
Miscellaneous
Output
GUI: RS-232 interface for computer display and configuration
ROM Upgrade: Flash upgradeable through RS-232
Power Requirements
Watts: 100-240V - 50/60 Hz
35 Watts
Dimensions
Dimensions: Height- 1.75” X Width- 19” X Depth 7.90”
Weight 8 lbs.
Shipping Weight: 9.5 lbs.
Specifications ( 241 DriveRack™)
Inputs
Number of Inputs: 2
Connectors: XLR, Euroblock
Type: Electronically balanced/RF filtered
Impedance: >40kΩ
Maximum Input Level: Hardware selectable for +30, +22, +14, dBu
CMRR: >40 dB typical, >55 dB at 1kHz
Outputs
Number of Outputs: 4
Connectors: XLR, Euroblock
Type: Electronically balanced, RF filtered
Impedance: 30Ω
Max Output Level: +25.5 dBu into 1kΩ
+22dBu into 600Ω
System Performance
Type: dbx Type IV™ Conversion System
Dynamic Range line: >105 dB unweighted, 108 dB A-weighted
Type IV™ dynamic range: 120 dB with transient material,
A-weighted, 22kHz BW
118 dB with transient material,
unweighted, 22kHz BW
112 dB typical with program material,
A-weighted, 22kHz BW
Sample Rate: 48kHz
