Figure 15. Removing the bezel lter
Next step
1 Follow the procedure listed in After working inside your system.
2 If applicable, install the front bezel to the system.
Installing the bezel lter
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Remove the front bezel.
Steps
1 Insert the lter into the bezel.
2 Insert the lter frame into the bezel and align the screw hole on the lter frame with the corresponding hole on the bezel.
3 Secure the lter frame with the screw.
Installing and removing system components
57
