Figure 59. Installing the IDSDM or vFlash module
Next steps
1 Install the MicroSD cards.
NOTE
: Reinstall the MicroSD cards into the same slots based on the labels you had marked on the cards during
removal.
2 Install the air shroud.
3 Follow the procedure listed in After working inside your system.
Removing the MicroSD card
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the air shroud.
Steps
1 Locate the MicroSD card slot on the IDSDM or vFlash module, and press the card to partially release it from the slot.
2 Hold the MicroSD card and remove it from the slot.
NOTE
: Temporarily label each MicroSD card with its corresponding slot number after removal.
Next step
Install the MicroSD cards.
98
Installing and removing system components
