Table 4 Embedded module LEDs (continued)
LED Location State Description
Blue and
amber
alternating
(green for 3
seconds)
System not initialized. A
management IP address has
not been assigned.
Blue and
amber
alternating at
one second
intervals
Storage processor assembly
in Service Mode.
Off No fault has occurred, normal
operation.
Storage processor assembly
power
Green Storage processor assembly
is on (main power).
Green blinking Storage processor assembly
is initializing a serial over LAN
session (Standby Mode).
Off Storage processor assembly
is off.
Unsafe to remove White Do not remove the embedded
module. Improper removal
could cause data loss.
Off Safe to remove the embedded
module when the embedded
module has been properly
prepared.
Remove a faulted embedded module
Procedure
1. Label and disconnect all cables attached to the embedded module.
2. Push the orange tab to release the lever.
Service Procedures
Remove a faulted embedded module 51
