Dell PowerConnect 3524P

Configuring Switch Information 331
Defining STP Port Settings
Use the STP Port Settings page to assign STP properties to individual ports.
To open the STP Port Settings page, click Switch → Spanning Tree → Port Settings in the tree view.
Figure 7-36. STP Port Settings
Name State Prio.Nbr Cost Sts Role PortFast Type
---- ----- ------- ---- --- ---- ------- ----
1/e5 enabled 128.2 19 FRW Desg Yes P2p Intr
1/e7 enabled 128.7 19 DSCR Altn No P2p Bound (STP)
1/e11 enabled 128.11 19 FRW Desg Yes P2p Intr
1/e15 enabled 128.15 19 FRW Desg No P2p Intr
1/e22 enabled 128.22 19 FRW Desg Yes P2p Intr
