Viewing Statistics 419
• Frames Transmit — Indicates the number of EAPOL frames transmitted via the port.
•
Start Frames Receive — Indicates the number of EAPOL Start frames received on the port.
•
Log off Frames Receive — Indicates the number of EAPOL Logoff frames received on the port.
•
Respond ID Frames Receive — Indicates the number of EAP Resp/Id frames received on the port.
•
Respond Frames Receive — Indicates the number of valid EAP Response frames received on the port.
•
Request ID Frames Transmit — Indicates the number of EAP Req/Id frames transmitted via the port.
•
Request Frames Transmit — Indicates the number of EAP Request frames transmitted via the port.
•
Invalid Frames Receive — Indicates the number of unrecognized EAPOL frames that have been
received on this port.
•
Length Error Frames Receive — Indicates the number of EAPOL frames with an invalid Packet Body
Length received on this port.
•
Last Frame Version — Indicates the protocol version number attached to the most recently received
EAPOL frame.
•
Last Frame Source — Indicates the source MAC address attached to the most recently received
EAPOL frame.
Displaying EAP statistics for a port
1 Open the EAP Statistics page.
2 Select an interface in the Interface field.
The interface EAP statistics are displayed.
To reset the EAP Statistics
1 Open the EAP Statistics page.
2 Click Reset All Counters .
The EAP statistics counters are reset.
Viewing EAP Statistics Using the CLI Commands
The following table summarizes the CLI commands for viewing EAP statistics.
Table 8-4. EAP Statistics CLI Commands
CLI Command Description
show dot1x statistics Displays 802.1X statistics for the
specified interface.
