Dell PowerConnect 3524P User Manual

436 Viewing Statistics
Viewing Port Statistics
Use the Port Statistics page to open statistics in a chart form for port elements. To open the Port
Statistics page, click Statistics/RMON→ Charts→ Port Statistics in the tree view.
Figure 8-14. Port Statistics
The Port Statistics page contains the following fields:
• Unit No. — Indicates the stacking unit for which the statistics are displayed.
•
Interface Statistics — Selects the interface statistics to display.
•
Etherlike Statistics — Selects the Etherlike statistics to display.
•
RMON Statistics — Selects the RMON statistics to display.
•
GVRP Statistics — Selects the GVRP statistics type to display.
•
Refresh Rate — Amount of time that passes before the statistics are refreshed.
Displaying Port Statistics
1 Open the Port Statistics page.
2 Select the statistic type of to open.
3 Select the desired refresh rate from the Refresh Rate drop-down menu.
4 Click Draw .
The graph for the selected statistic is displayed.

Dell PowerConnect 3524P Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	-
Number of VLANs	256
Flow control support	Yes
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad
Dimensions (WxDxH)	440 x 387 x 43.2 mm
Power requirements	100-240VAC, 50-60Hz
Networking features	Gigabit Ethernet, Fast Ethernet
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet
Supported network protocols	HTTP, HTTPS/SSL, SSH
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	8000 g
