364 Configuring Switch Information
Removing a MAC to VLAN Binding:
1
Open the
Bind MAC to VLAN
page.
2
Click
Show All
. The
MAC to VLAN Table
opens.
3
Select the desired VLAN, or select
All
to see bindings for all VLANs.
4
Select the
Remove
checkbox next to the desired bindings.
5
Click
Apply Changes
.
Binding MAC address to VLAN using CLI commands:
The following table summarizes the equivalent CLI commands for binding MAC addresses to VLAN.
The following is an example of the CLI commands:
console(config-vlan)# mac-to-vlan 0060.704c.73ff 123
console(config-vlan)# exit
console(config)# exit
console# show vlan mac-to-vlan
MAC Address VLAN
------------ ------
0060.704c.73ff 123
Defining VLAN Protocol Groups
The Protocol Group page provides parameters for configuring frame types to specific protocol groups.
To open the Protocol Group page, click Switch → VLAN → Protocol Group in the tree view.
Table 7-29. Binding MAC address to VLANs CLI Commands
CLI Command Description
mac-to-vlan mac-address vlan-id
Binds the MAC address to the VLAN.
switchport access vlan dynamic Configures private VLANs.
show mac-to-vlan Displays the MAC to VLAN database
no mac-to-vlan mac-address
Unbinds the MAC address from the VLAN.
