Installing the PowerConnect 3524/P and PowerConnect 3548/P 43
Figure 3-3. Mounting a Device on a Wall
Connecting to a Terminal
1 Connect an RS-232 crossover cable to the ASCII terminal or the serial connector of a desktop system
running terminal emulation software.
2 Connect the female DB-9 connector at the other end of the cable to the device serial port connector.
Fro n t Pan e l
Drilled
Holes
Wal l
Drilled
Holes
