Viewing Statistics 423
The following is an example of the CLI commands:
Viewing RMON History Control Statistics
The RMON History Control contains information about samples of data taken from ports. For example,
the samples may include interface definitions or polling periods. To open the RMON History Control
page, click Statistics/RMON→ RMON→ History Control in the tree view.
Figure 8-8. RMON History Control
console# show rmon statistics ethernet 1/e1
Port 1/e1
Dropped: 8
Octets: 878128 Packets: 978
Broadcast: 7 Multicast: 1
CRC Align Errors: 0 Collisions: 0
Undersize Pkts: 0 Oversize Pkts: 0
Fragments: 0 Jabbers: 0
64 Octets: 98 65 to 127 Octets: 0
128 to 255 Octets: 0 256 to 511 Octets: 0
512 to 1023 Octets: 491 1024 to 1632 Octets: 389
