40 Installing the PowerConnect 3524/P and PowerConnect 3548/P
• Rack-mount kit for rack installation or wall mounting kit
• Documentation CD
• Product Information Guide
Unpacking the Device
NOTE: Before unpacking the device, inspect the package and immediately report any evidence of damage.
1
Place the box on a clean flat surface.
2
Open the box or remove the box top.
3
Carefully remove the device from the box and place it on a secure and clean surface.
4
Remove all packing material.
5
Inspect the device and accessories for damage. Report any damage immediately.
Mounting the Device
The following mounting instructions apply to The PowerConnect 3524/P and PowerConnect 3548/P
devices. The Console port is on the back panel. The power connectors are positioned on the back panel.
Connecting a Redundant Power Supply (RPS) is optional, but is recommended. The RPS connector is
on the back panel of the devices.
Installing in a Rack
WARNING: Read the Safety Information included in the Product Information Guide for safety information on
devices connected to or that support the SWI.
WARNING: Disconnect all cables from the unit before mounting the device in a rack or cabinet.
WARNING: When mounting multiple devices into a rack, mount the devices from the bottom up.
