146 Configuring System Information
Displaying Optical Transceiver Diagnostics Test Results Table
1 Open the Optical Transceiver Diagnostics page.
2 Click Show All .
The test is run and the
Virtual Cable Test Results Table opens.
The Optical Transceiver Diagnostics Table contains the following columns:
• Temp — Internally measured transceiver temperature.
•
Voltage — Internally measured supply voltage.
•
Current — Measured TX bias current.
•
Output Power — Measured TX output power in milliwatts.
•
Input Power — Measured RX received power in milliwatts.
•
TX Fault — Transmitter fault.
Finisair transceivers do not support the transmitter fault diagnostic testing.
• LOS — Loss of signal.
•
Data Ready — The transceiver has archived power up and data is ready.
•
N/A — Not Available, N/S - Not Supported, W - Warning, E - Error.
Fiber Optic analysis feature works only on SFPs that support the digital diagnostic standard SFF-4872.
Performing Fiber Optic Cable Tests Using CLI Commands
The following table summarizes the equivalent CLI command for performing fiber optic cable tests.
Table 6-29. Fiber Optic Cable Test CLI Commands
CLI Command Description
show fiber-ports optical-transceiver
[interface]
[detailed]
Displays the optical transceiver
diagnostics.

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
