Dell PowerConnect 5424 User Manual

404 Viewing Statistics
The following is an example of the CLI commands:
Viewing Charts
The Chart page contains links for displaying statistics in a chart form. To open the page,
click Statistics→ Charts in the tree view.
Viewing Port Statistics
The Port Statistics page contains fields for opening statistics in a chart form for port elements. To open
the Port Statistics page, click Statistics→ Charts→ Ports in the tree view.
console> enable
console# config
Console (config)# rmon alarm 1000 dell 360000 1000000 1000000
10 20
Console# show rmon alarm-table
Index OID Owner
------ ------------------- --------------
1 1.3.6.1.2.1.2.2.1.1
0.1
CLI
2 1.3.6.1.2.1.2.2.1.1
0.1
Manager
3 1.3.6.1.2.1.2.2.1.1
0.9
CLI

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
