Configuring System Information 181
Configuring LLDP and LLDP-MED
The Link Layer Discovery Protocol (LLDP) allows network managers to troubleshoot and enhance network
management by discovering and maintaining network topologies over multi-vendor environments. LLDP
discovers network neighbors by standardizing methods for network devices to advertise themselves to other
system, and to store discovered information. Device discovery information includes:
• Device Identification
• Device Capabilities
• Device Configuration
The advertising device transmits multiple advertisement message sets in a single LAN packet.
The multiple advertisement sets are sent in the packet Type Length Value (TLV) field. LLDP devices
must support chassis and port ID advertisement, as well as system name, system ID, system description,
and system capability advertisements.
This section includes the following topics:
• Defining Global LLDP Properties
• Defining LLDP Port Settings
• Defining Media Endpoint Discovery Network Policy
• Defining LLDP MED Port Settings
• Viewing the LLDP Neighbors Information
Console# show radius-servers
Port
IP address Auth Acct TimeOut Retransmit Deadtime Source
IP
Priority Usage
--------- ---- ---- ------- ---------- ------- ----- ------- -----
33.1.1.1 1812 1813 6 4 10 0.0.0.0 0 All
172.16.1.2 1645 1646 11 8 Global Global 2 All
Global values
--------------
TimeOut: 5
Retransmit: 5
Deadtime: 10
Source IP: 0.0.0.0
